Classification model#

This live example shows how to easily train, validate, optimize and export classification model on the flowers dataset from TensorFlow. To learn more about Classification task, refer to Classification.

Note

To learn deeper how to manage training process of the model including additional parameters and its modification, refer to Classification model.

The process has been tested on the following configuration.

  • Ubuntu 20.04

  • NVIDIA GeForce RTX 3090

  • Intel(R) Core(TM) i9-10980XE

  • CUDA Toolkit 11.8

Note

While this example shows how to work with multi-class classification, it is easy to extend it for the multi-label or hierarchical classification. Substitute the dataset with a multi-label or hierarchical one. Everything else remains the same.

Setup virtual environment#

1. You can follow the installation process from a quick start guide to create a universal virtual environment for OpenVINO™ Training Extensions.

2. Activate your virtual environment:

.otx/bin/activate
. venv/otx/bin/activate

Dataset preparation#

Download and prepare a flowers dataset with the following command:

To prepare the classification dataset, need to make the directory for the train/validation and test. Since this is just example, we’ll use the same train/val/test datasets.

cd data

# download and unzip the data
wget http://download.tensorflow.org/example_images/flower_photos.tgz
tar -xzvf flower_photos.tgz

# construct the data structure to insert to the OTX
cd flower_photos
mkdir train
mv daisy dandelion roses sunflowers tulips train
cp -r train val
cp -r train test

# move the original directory
cd ../..

../../../../_images/flowers_example.jpg

Then the final dataset directory likes below, please keep the exact same name for the train/val/test folder, to identify the dataset.

flower_photos
  train
    ├── daisy
    ├── dandelion
    ├── roses
    ├── sunflowers
    ├── tulips
  val
    ├── daisy
    ├── ...
  test
    ├── daisy
    ├── ...

Training#

1. First of all, you need to choose which classification model you want to train. The list of supported recipes for classification is available with the command line below.

Note

The characteristics and detailed comparison of the models could be found in Explanation section.

(otx) ...$ otx find --task MULTI_CLASS_CLS
┏━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┓
┃ Task            ┃ Model Name            ┃ Recipe Path                                                                                                 ┃
┡━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┩
│ MULTI_CLASS_CLS │ openvino_model        │ src/otx/recipe/classification/multi_class_cls/openvino_model.yaml                                           │
│ MULTI_CLASS_CLS │ tv_efficientnet_v2_l  │ src/otx/recipe/classification/multi_class_cls/tv_efficientnet_v2_l.yaml                                     │
│ MULTI_CLASS_CLS │ dino_v2               │ src/otx/recipe/classification/multi_class_cls/dino_v2.yaml                                                  │
│ MULTI_CLASS_CLS │ efficientnet_v2       │ src/otx/recipe/classification/multi_class_cls/efficientnet_v2.yaml                                          │
│ MULTI_CLASS_CLS │ tv_efficientnet_b3    │ src/otx/recipe/classification/multi_class_cls/tv_efficientnet_b3.yaml                                       │
│ MULTI_CLASS_CLS │ deit_tiny             │ src/otx/recipe/classification/multi_class_cls/deit_tiny.yaml                                                │
│ MULTI_CLASS_CLS │ mobilenet_v3_large    │ src/otx/recipe/classification/multi_class_cls/mobilenet_v3_large.yaml                                       │
│ MULTI_CLASS_CLS │ efficientnet_b0       │ src/otx/recipe/classification/multi_class_cls/efficientnet_b0.yaml                                          │
│ MULTI_CLASS_CLS │ tv_mobilenet_v3_small │ src/otx/recipe/classification/multi_class_cls/tv_mobilenet_v3_small.yaml                                    │
└─────────────────┴───────────────────────┴─────────────────────────────────────────────────────────────────────────────────────────────────────────────┘

from otx.backend.native.cli.utils import list_models

model_lists = list_models(task="MULTI_CLASS_CLS", pattern="*efficient")
print(model_lists)
'''
[
  'efficientnet_b0',
  'efficientnet_v2_light',
  'efficientnet_b0_light',
  ...
]
'''

1. On this step we will prepare custom configuration with:

  • all necessary configs for otx_efficientnet_b0

  • train/validation sets, based on provided annotation.

It may be counterintuitive, but for --data_root we need to pass the path to the dataset folder root (in our case it’s data/flower_photos) instead of the folder with validation images. This is because the function automatically detects annotations and images according to the expected folder structure we achieved above.

Let’s check the multi-class classification configuration running the following command:

(otx) ...$ otx train --config src/otx/recipe/classification/multi_class_cls/mobilenet_v3_large.yaml  --data_root data/flower_photos --print_config

...
data_root: data/flower_photos
work_dir: otx-workspace
callback_monitor: val/accuracy
disable_infer_num_classes: false
engine:
  task: MULTI_CLASS_CLS
  device: auto
data:
...

Note

If you want to get configuration as yaml file, please use --print_config parameter and > configs.yaml.

(otx) ...$ otx train --config  src/otx/recipe/classification/multi_class_cls/mobilenet_v3_large.yaml --data_root data/flower_photos --print_config > configs.yaml
# Update configs.yaml & Train configs.yaml
(otx) ...$ otx train --config configs.yaml

3. otx train trains a model (a particular model recipe) on a dataset and results:

Here are the main outputs can expect with CLI: - {work_dir}/{timestamp}/checkpoints/epoch_*.ckpt - a model checkpoint file. - {work_dir}/{timestamp}/configs.yaml - The configuration file used in the training can be reused to reproduce the training. - {work_dir}/.latest - The results of each of the most recently executed subcommands are soft-linked. This allows you to skip checkpoints and config file entry as a workspace.

(otx) ...$ otx train --config src/otx/recipe/classification/multi_class_cls/mobilenet_v3_large.yaml --data_root data/flower_photos

from otx.backend.native.engine import OTXEngine

data_root = "data/flower_photos"
recipe = "src/otx/recipe/classification/multi_class_cls/mobilenet_v3_large.yaml"

engine = OTXEngine.from_config(
          config_path=recipe,
          data_root=data_root,
          work_dir="otx-workspace",
        )

# it is also possible to pass a config as a model to the Engine directly
engine = OTXEngine(
          model=recipe,
          data=data_root,
          work_dir="otx-workspace",
        )

# one more possibility to obtain the right engine by the given model/dataset
# using "create_engine" function
from otx.engine import create_engine
engine = create_engine(
          model=recipe,
          data=data_root,
        )

engine.train()

from otx.backend.native.engine import OTXEngine
from otx.backend.native.models import MobileNetV3MulticlassCls

data_root = "data/flower_photos"
model = MobileNetV3MulticlassCls(label_info = {"label_names": ["daisy", "dandelion", "roses", "sunflowers", "tulips"],
                                       "label_id": [0, 1, 2, 3, 4],
                                       "label_groups": [["daisy", "dandelion", "roses", "sunflowers", "tulips"]]},
                         data_input_params = {"input_size": [224, 224],
                                             "mean": [123.675, 116.28, 103.53],
                                             "std": [58.395, 57.12, 57.375]})

engine = OTXEngine(
          model=model,
          data=data_root,
          work_dir="otx-workspace",
        )

# one more possibility to obtain the right engine by the given model/dataset
# using "create_engine" function
from otx.engine import create_engine
engine = create_engine(
          model=model,
          data=data_root,
        )

engine.train(...)

4. (Optional) Additionally, we can tune training parameters such as batch size, learning rate, patience epochs or warm-up iterations. Learn more about specific parameters using otx train --help -v or otx train --help -vv.

For example, to decrease the batch size to 4, fix the number of epochs to 100, extend the command line above with the following line.

(otx) ...$ otx train ... --data.train_subset.batch_size 4 \
                         --max_epochs 100

from otx.config.data import SubsetConfig
from otx.data.module import OTXDataModule
from otx.backend.native.engine import OTXEngine

datamodule = OTXDataModule(..., train_subset=SubsetConfig(..., batch_size=4))

engine = OTXEngine(..., data=datamodule)

engine.train(max_epochs=100)

5. The training result checkpoints/*.ckpt file is located in {work_dir} folder, while training logs can be found in the {work_dir}/{timestamp} dir.

Note

We also can visualize the training using Tensorboard as these logs are located in {work_dir}/{timestamp}/tensorboard.

otx-workspace
├── 20240403_134256/
    ├── csv/
    ├── checkpoints/
    |   └── epoch_*.pth
    ├── tensorboard/
    └── configs.yaml
└── .latest
    └── train/
...

The training time highly relies on the hardware characteristics, for example on 1 NVIDIA GeForce RTX 3090 the training took about 3 minutes.

After that, we have the PyTorch multi-class classification model trained with OpenVINO™ Training Extensions, which we can use for evaluation, export, optimization and deployment.

6. It is also possible to resume training from the last checkpoint. For this, we can use the --resume parameter with the path to the checkpoint file.

(otx) ...$ otx train --config src/otx/recipe/classification/multi_class_cls/mobilenet_v3_large.yaml \
                      --data_root data/flower_photos \
                      --checkpoint otx-workspace/20240403_134256/checkpoints/epoch_014.ckpt \
                      --resume True

from otx.backend.native.engine import OTXEngine
engine = OTXEngine(model="src/otx/recipe/classification/multi_class_cls/mobilenet_v3_large.yaml", data="data/flower_photos", work_dir="otx-workspace")

engine.train(resume=True,
             checkpoint="otx-workspace/20240403_134256/checkpoints/epoch_014.ckpt")

Evaluation#

1. otx test runs evaluation of a trained model on a particular dataset.

Test function receives test annotation information and model snapshot, trained in previous step.

The default metric is accuracy measure.

2. That’s how we can evaluate the snapshot in otx-workspace folder on flower_photos dataset and save results to otx-workspace:

(otx) ...$ otx test --work_dir otx-workspace
┏━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━┓
┃        Test metric        ┃       DataLoader 0        ┃
┡━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━┩
│      test/data_time       │    0.9929155111312866     │
│       test/map_50         │    0.0430680550634861     │
│      test/iter_time       │    0.058606021106243134   │
└───────────────────────────┴───────────────────────────┘

(otx) ...$ otx test --config  src/otx/recipe/classification/multi_class_cls/mobilenet_v3_large.yaml \
                    --data_root data/flower_photos \
                    --checkpoint otx-workspace/20240312_051135/checkpoints/epoch_014.ckpt
┏━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━┓
┃        Test metric        ┃       DataLoader 0        ┃
┡━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━┩
│      test/data_time       │    0.9929155111312866     │
│       test/map_50         │    0.0430680550634861     │
│      test/iter_time       │    0.058606021106243134   │
└───────────────────────────┴───────────────────────────┘

metric = engine.test()

3. The output of {work_dir}/{timestamp}/csv/version_0/metrics.csv consists of a dict with target metric name and its value.

The next tutorial on how to export, optimize, and deploy the model is available at Deploy & Demo.
